IEC 60320 Gauge โ Precision Go/No-Go Gauge Set for Connectors and Appliance Inlets
IEC 60320 Gauge for Plug Pin performs precision Go/Not Go testing for connectors and appliance inlets.
- Comprehensive gauge set: complete collection of โGoโ and โNot Goโ gauges covering standard sheets C1, C5, C7, C8, C9, C10, C13, C14, C15, C16, C17, C18, C19, C20, C21, C22, C23 and C24
- Precision 430 stainless steel construction: hardness โฅ60 HRC and surface roughness per standard requirements
- Multiple verification functions: dimensional checking, resistance to deformation, and distance from engagement face to first contact point
- Calibration report included: traceable ISO 9001 and CE certified quality assurance
- MOQ: 1
- Delivery Period: To be quoted
IEC 60320 Gauge Description
IEC60320 Gauge For Plug & Pin List.EN60320 Gauge For Plug & Pin List.IEC60320-3 GAUGE
The IEC 60320 Gauge is a complete precision gauge set manufactured by KingPo for testing and verification of plugs, connectors and appliance inlets according to IEC 60320-1 and IEC 60320-2-2 (EN 60320). Each gauge is produced from 430 stainless steel with hardness โฅ60 HRC and surface finish meeting the exact requirements of the standard, ensuring accurate dimensional compliance and reliable safety verification for worldwide markets.
Testing Principle
The gauges check critical dimensions, insertion/withdrawal characteristics, resistance to deformation of the front part, and distance from the engagement face to the point of first contact. โGoโ gauges verify maximum/minimum acceptable dimensions while โNot Goโ gauges confirm that out-of-tolerance parts are rejected, fully satisfying the mechanical and safety requirements of IEC 60320.
KingPo Factory Advantages
KingPo is an ISO 9001, ISO 14001, ISO 45001 and CE certified manufacturer, also holding SGS, PSE and RoHS certifications. We specialize in electrical safety testing equipment and have supplied IEC 60320 gauge sets to manufacturers and certification laboratories worldwide. Each unit undergoes rigorous calibration and is delivered with complete documentation, on-site installation guidance, a full one-year warranty and lifetime technical support from our Dongguan facility.
Professional Construction & Technical Precision
Key features include:
- Precision 430 stainless steel construction with hardness โฅ60 HRC for long-term dimensional stability
- Full coverage of IEC 60320-1 and IEC 60320-2-2 standard sheets including Figures 2โ27 for all common connector types
- Specialized deformation and distance gauges (Figure 22 and Figure 27) for comprehensive verification
- Calibration report supplied with every set for full traceability
These elements ensure accurate, repeatable and standard-compliant testing results.
Technical Parameters
| Parameter | Specification | Remark / Notes |
|---|---|---|
| Standard | IEC 60320-1 & IEC 60320-2-2 (EN 60320) | Covers all common connector and appliance inlet sheets |
| Material | 430 stainless steel | Hardness โฅ60 HRC, surface roughness per standard |
| Gauge Set | Complete โGoโ / โNot Goโ set (Figures 2โ27) | Includes C1, C5, C7, C8โC24 series gauges |
| Functions | Dimensional check, deformation resistance, engagement distance | Full mechanical and safety verification |
| Calibration | Calibration report included | Traceable to national standards |
| Packing | Special protective box | Ensures gauge integrity during transport |
The IEC 60320 Gauge is used to verify dimensional accuracy and functional performance of plugs, connectors and appliance inlets during product development, production quality control and third-party certification. It helps manufacturers ensure compliance with international safety standards and maintain consistent product quality.
Procurement Benefits
The gauge set offers precision 430 stainless steel construction, complete coverage of all relevant standard sheets and a traceable calibration report in a durable protective box. It provides consistent, repeatable test results with minimal maintenance, making it a practical solution for IEC 60320 compliance testing.
Compliance & Regulatory Assurance
This equipment is designed and manufactured in accordance with IEC 60320-1 and IEC 60320-2-2 for testing plugs, connectors and appliance inlets. It provides a standardized method to verify dimensional compliance and mechanical safety, ensuring products meet the required international safety and quality levels.
For detailed information on IEC 60320 testing, please refer to the latest editions of IEC 60320-1 and IEC 60320-2-2.
Regular verification of gauge dimensions is recommended to maintain traceability.
Technical Inquiry for IEC 60320 Gauge
KingPo specializes in electrical safety testing equipment. If you require precise IEC 60320 plug pin gauges, our engineering team can provide technical support and configuration recommendations.
The Core Value We Deliver to You
- Complete set of โGoโ / โNot Goโ gauges for all major IEC 60320 connector sheets
- Precision 430 stainless steel construction with โฅ60 HRC hardness
- Full coverage of dimensional, deformation and engagement-distance checks
- Calibration report included for immediate traceability
- Durable special packing box for long-term gauge protection
Tell us your required connector type or standard sheet โ our engineering team will reply with tailored recommendations within 24 hours.
Specification:
| Standard | Product Name |
|---|---|
| IEC60320-1-Figure 2 | โGoโ gauge for connectors to standard sheet C1 |
| IEC60320-1- Figure4 | โGoโ gauge for connectors to standard sheet C5 |
| IEC60320-1- Figure5 | โGoโ gauge for connectors to standard sheet C7 |
| IEC60320-1- Figure5A | โGoโ gauge for side-entry connectors to standard sheet C7 |
| IEC60320-1- Figure6 | โNot Goโ gauge for connectors to standard sheet C1 |
| IEC60320-1- Figure7 | โNot Goโ gauge for connectors to standard sheet C1,C5 and C7 |
| IEC60320-1- Figure8 | โNot Goโ gauge for connectors to standard sheet C1 and C7 |
| IEC60320-1- Figure9 | โNot Goโ gauge for appliance inlets to standard sheet C8,C8A and C8B |
| IEC60320-1- Figure9A | โGoโ gauge for connectors to standard sheet C9 |
| IEC60320-1- Figure9B | โNot Goโ gauge for connectors to standard sheet C9 |
| IEC60320-1- Figure9C | โGoโ gauge for appliance inlets to standard sheet C10 |
| IEC60320-1- Figure9F | โGoโ gauge for connectors to standard sheet C13 |
| IEC60320-1- Figure9G | โNot Goโ gauge for connectors to standard sheet C13 and C17 |
| IEC60320-1- Figure 9H | โGoโ gauge for appliance inlets to standard sheets C14, C16 AND C18 |
| IEC60320-1- Figure 9J | โGoโ gauge for connectors to standard sheet C15 |
| IEC60320-1- Figure 9K | โGoโ gauge for connectors to standard sheet C17 |
| IEC60320-1- Figure 9L | โGoโ gauge for connectors to standard sheet C19 |
| IEC60320-1- Figure 9M | โGoโ gauge for appliance inlets to standard sheet C20 and C24 |
| IEC60320-1- Figure 9N | โGoโ gauge for connectors to standard sheet C21 |
| IEC60320-1- Figure 9P | โGoโ gauge for appliance inlets to standard sheet C22 |
| IEC60320-1- Figure 9Q | โGoโ gauge for appliance inlets to standard sheet C23 |
| IEC60320-1- Figure 9R | โNot Goโ gauge for connectors to standard sheet C13,C15 and C17 |
| IEC60320-1- Figure 9S | โGoโ gauge for connectors to standard sheet C15A |
| IEC60320-1- Figure 9T | โGoโ gauge for appliance inlets to standard sheet C16A |
| IEC60320-1- Figure 22 | Blades for checking the resistance against deformation of the front part of the connector to standard sheet C7 |
| IEC60320-1- Figure 27 | Gauges for checking the distance from the engagement face of connectors to the point of first contact |
| IEC60320-2-2 Figure 101 | โGoโ gauge for appliance outlets to standard sheet F (see 8.1) |
| IEC60320-2-2 Figure 103 | โGoโ gauge for appliance outlets to standard sheet J (see 8.1) |
