Flame Test Equipment – IEC 60695 Compliant Flammability & Combustion Testers | KingPo
Browse KingPo flame, ignition and flammability test equipment for electrical products, insulating materials, cables, automotive components and other applications.
The available product range includes glow-wire, needle-flame, 50 W and 500 W test-flame systems, cable flame test chambers, material flammability testers, calibration accessories and supporting tools. Equipment should be selected according to the applicable test method, product standard, specimen type, burner specification and required calibration scope.
KingPo Core Flame & Combustion Test Series
KingPo supplies flame, ignition and flammability test equipment for evaluating the fire hazards of electrical products, insulating materials, cables, automotive components and other specimens.
Main equipment includes:
- Glow-Wire Test Apparatus — supports glow-wire testing according to IEC 60695-2-10, IEC 60695-2-11, IEC 60695-2-12 and IEC 60695-2-13.
- Needle Flame Tester — supports small-flame fault-condition testing according to IEC 60695-11-5.
- 50 W Flame Test Apparatus — for test flames and applicable horizontal and vertical burning methods, configured according to IEC 60695-11-4 and the relevant product or material standard.
- 500 W Flame Test Apparatus — for higher-power test-flame applications according to IEC 60695-11-3 and applicable product or material standards.
- Hot Flaming Oil Test Apparatus — for legacy IEC 60950-1 Annex A.3 projects and customer specifications that continue to reference this method.
- Burner Calibration and Verification Devices — including copper blocks, thermocouples, flame-height gauges and related accessories selected according to the applicable 50 W or 500 W test-flame method.
Available configurations include programmable controls, stable gas-flow regulation, flame-height adjustment, safety interlocks, exhaust systems and applicable calibration accessories. The final equipment configuration should be selected according to the test method, specimen type, product standard, gas supply and required calibration scope.
Flame Test Equipment Configuration Support
Confirm the applicable standard, test method, specimen type, burner rating, gas supply, chamber requirements and calibration scope with KingPo before quotation.
flame-test-equipment Applications
Testing plastic enclosures, PCBs, connectors, switches, and insulating materials for ignition and flame spread (Glow Wire, Needle Flame, 50W/500W tests).Household Appliances — Assessing flame retardancy of casings, power cords, internal wiring in appliances like refrigerators, air conditioners, washing machines.
Flammability evaluation of interior materials, insulation and selected components according to applicable methods such as FMVSS 302, ISO 3795 or customer-specified automotive requirements.
Evaluation of polymer enclosures, insulating parts, separators and related materials using the applicable flammability method. These tests characterize ignition or flame behaviour but do not replace battery thermal-runaway, propagation or abuse testing.
Verifying flame resistance of lamp holders, diffusers, ballasts, and LED housings.
Horizontal/vertical burning tests for raw plastics, textiles, foams, and composite materials.
Flame propagation and resistance testing for power cables, communication cables, and insulation sheaths.
Flame Test Equipment FAQs
KingPo supplies equipment configured for selected methods within the IEC 60695 series, UL 94, GB/T 5169, IEC 60332, UL 1581, FMVSS 302 and other applicable product or material standards. The exact standard, edition, burner, specimen arrangement and verification requirements should be confirmed for each project.
Glow Wire simulates heat from overloaded components (IEC 60695-2-10), while Needle Flame evaluates small flame faults inside products (IEC 60695-11-5).
Calibration or verification documentation is available for applicable burners, copper blocks, thermocouples, temperature-measurement components and flame-height gauges. The exact calibration items, measurement points, issuing laboratory and traceability scope should be confirmed before ordering.
Yes, widely used for battery casings, automotive interiors, plastic enclosures, and electronic components fire safety evaluation.
These are separate test methods with different burners, flame characteristics, specimen arrangements and evaluation requirements. The needle-flame method is covered by IEC 60695-11-5, while 50 W and 500 W test flames are specified through their respective test-flame methods. The applicable product or material standard should be confirmed before equipment selection.
Yes, we offer global after-sales service, technical support, and original spare parts supply.
