Unsymmetrical Coupled Decoupling Network DATA-CDN-4B โ IEC 61000-4-5 Surge Coupling Device
Unsymmetrical Coupled Decoupling Network DATA-CDN-4B supports 1.2/50 ฮผs and 10/700 ฮผs surge testing up to 6 kV on 10/100/1000M Ethernet lines with pluggable resistance and effective decoupling for accurate immunity evaluation.
- Standard Compliance: IEC 61000-4-5, ITU-T K.20/K.21/K.45 โ unsymmetrical coupled decoupling network for surge immunity
- Voltage Waveform: 1.2/50 ฮผs open circuit and 10/700 ฮผs waveform output up to 6 kV
- Matching Resistance: Pluggable 25ฮฉ, 40ฮฉ, 100ฮฉ, 160ฮฉ, 200ฮฉ, 320ฮฉ โ flexible line impedance matching
- Coupling/Decoupling: 0.5 ฮผF capacitor, 90V gas discharge tube, optional clamp circuit; 20 mH decoupled inductor
- Network Support: 10M/100M/1000M Ethernet ports
- MOQ: 1
- Price: To be quoted
Unsymmetrical Coupled Decoupling Network Description
Unsymmetrical Coupled Decoupling Network โ DATA-CDN-4B Surge Tester for IEC 61000-4-5 Compliance
The Unsymmetrical Coupled Decoupling Network (DATA-CDN-4B) is a critical component for simulating lightning strikes and industrial switching transients on communication lines. As a specialized surge immunity test equipment, it enables the injection of high-voltage pulses onto high-speed data paths while isolating the auxiliary equipment from the test surge.
Testing rinciple
The network couples the surge waveform (10/700 ฮผs) from the generator to the equipment under test through a 0.5 ฮผF capacitor while the 20 mH decoupled inductor isolates the auxiliary equipment. Pluggable matching resistors allow precise impedance matching to the communication line, ensuring accurate and repeatable surge immunity testing according to IEC 61000-4-5 and related ITU-T recommendations.
KingPo Factory Advantages
KingPo is an ISO 9001, ISO 14001, ISO 45001 and CE certified manufacturer, also holding SGS, PSE and RoHS certifications. We specialize in surge immunity and electrical safety testing equipment and have supplied DATA-CDN-4B Unsymmetrical Coupled Decoupling Networks to telecommunication equipment manufacturers and certification laboratories worldwide. Each unit undergoes rigorous calibration and is delivered with complete documentation, on-site installation guidance, a full one-year warranty and lifetime technical support from our Dongguan facility.
Professional Construction & Technical Precision
Key features include:
- Optimized 10/700 ฮผs decoupling network with 6 kV maximum test voltage and 0.5 ฮผF coupling capacitor for maximum energy transfer
- Gigabit network compatibility supporting 10M/100M/1000M Ethernet ports for modern IT infrastructure testing
- Pluggable resistance system (25 ฮฉ, 40 ฮฉ, 100 ฮฉ, 160 ฮฉ, 200 ฮฉ, 320 ฮฉ) for flexible line impedance matching
- 20 mH decoupled inductor for effective isolation of high-voltage transients from auxiliary equipment
- Robust shielded enclosure (440 ร 350 ร 150 mm) ensuring safety and stable operation
- High anti-interference design for reliable surge coupling and decoupling performance
These elements ensure high accuracy, excellent repeatability and full compliance with IEC 61000-4-5 requirements.
Technical Parameters
| Parameter | Specification | Remark / Notes |
|---|---|---|
| Model | DATA-CDN-4B | Unsymmetrical Coupled Decoupling Network |
| Max Test Voltage | 6 kV | 10/700 ฮผs waveform |
| Coupling Capacitor | 0.5 ฮผF | High energy transfer |
| Decoupled Inductor | 20 mH | Effective transient isolation |
| Matching Resistance | 25 ฮฉ, 40 ฮฉ, 100 ฮฉ, 160 ฮฉ, 200 ฮฉ, 320 ฮฉ (pluggable) | Flexible impedance matching |
| Network Support | 10M/100M/1000M Ethernet | Gigabit data line testing |
| Gas Discharge Tube | 90 V | Surge protection |
| Dimensions / Weight | 440 ร 350 ร 150 mm / 10 kg | Compact and portable |
The Unsymmetrical Coupled Decoupling Network is used to validate surge protection of telecommunication lines, Gigabit switches, routers, IP cameras, VoIP devices and other high-speed data ports. It supports product development, certification testing and quality assurance, helping manufacturers ensure equipment meets international surge immunity requirements and reduces the risk of transient-induced failures.
Procurement Benefits
The network offers precise waveform coupling, pluggable resistance matching, Gigabit Ethernet support and a robust shielded enclosure in a compact, easy-to-operate design. It delivers consistent, repeatable surge immunity test results with minimal maintenance, making it a practical solution for telecommunication and data line testing.
Compliance & Regulatory Assurance
This equipment is designed and manufactured in accordance with IEC 61000-4-5 and CISPR 16-1-2 for surge immunity testing. It provides a standardized method to couple and decouple high-voltage transients while protecting auxiliary equipment, ensuring communication lines and data ports meet the required surge protection levels for electrical safety and regulatory compliance.
For detailed information on surge immunity testing, please refer to the latest edition of IEC 61000-4-5.
Regular verification of coupling capacitor, decoupled inductor and matching resistance is recommended to maintain traceability.
Technical Inquiry for Unsymmetrical Coupled Decoupling Network
KingPo specializes in surge immunity and electrical safety testing equipment. If you require precise IEC 61000-4-5 decoupling network testing, our engineering team can provide technical support and configuration recommendations.
The Core Value We Deliver to You
- 10/700 ฮผs decoupling network with 6 kV maximum test voltage
- Pluggable matching resistance for flexible impedance matching
- 20 mH decoupled inductor for effective transient isolation
- Gigabit Ethernet support for modern data line testing
- Robust shielded enclosure for stable and safe operation
Tell us your test waveform or line type โ our engineering team will reply with tailored recommendations within 24 hours.
