Three Comprehensive Environmental Testing Equipment , Climatic Test Chamber
Three Comprehensive Environmental Test Chambers integrate temperature, humidity, and vibration testing for reliable product validation under extreme conditions.
MOQ: 1
Price: To be quoted
Standard Packaging: safety carton pack or plywood box
Delivery Period: 35 working days
Payment Method: T/T
Supply Capacity: 3 sets per month
Product Description
Series of three integrated main chamber for the aerospace, aviation, petroleum, chemical, electronics, communications, and other research and production units to provide temperature and humidity changes in the environment, while the electric vibration test chamber in accordance with the provisions of the cycle of stress applied to the test product , and for users of the machine (or parts), electrical appliances, equipment, materials for temperature and humidity, vibration stress screening test integrated to the adaptability of the test product evaluation or to evaluate the behavior of the test product.
Detail Information
| Place of Origin | China | Brand Name | Kingpo |
| Certification | Iso9001 Ce | Temp. Range: | -70 ~ -20 ~ +150โ |
| Humidity Rage: | 20 ~98%RH | Temp. Fluctuation: | ยฑ0.5โ |
| Temp. Difference: | ยฑ2โ | Humidity Difference: | ยฑ3.0%RH๏ผ>75%RH๏ผ,ยฑ5.0%RH,ยฑ5.0%RH๏ผโค75%RH๏ผ |
| Highlight: | temperature and humidity chamber, climatic test chamber | ||
Get Free Quote of Three Comprehensive Environmental Testing Equipment , Climatic Test Chamber
Technical Parameters
| Type | KP-ZH150 | KP-ZH225 | KP-ZH408 | KP-ZH500 | KP-ZH800 | KP-ZH1000 | ||
| Nominal Innage(L) | 150 | 225 | 408 | 500 | 800 | 1000 | ||
| Properties | Temp. range | -70 ~ -20 ~ +150โ | ||||||
| Humidity rage | 20 ~98%RH | |||||||
| Temp. fluctuation | ยฑ0.5โ | |||||||
| Temp. difference | ยฑ2โ | |||||||
| Humidity difference | ยฑ3.0%RH(>75%RH),ยฑ5.0%RH,ยฑ5.0%RH(โค75%RH) | |||||||
| Heating time | -20 ~ +150โ | -40 ~ +150โ
|
-70 ~ +150โ | |||||
| โค60min | ||||||||
| Cooling time | +20 ~ +20โ | +20 ~ +40โ | +20 ~ +70โ | |||||
| โค45min | โค60min | โค80min | ||||||
| Temperature and humidity mode | BT(H)C Balanced temperature and humidity control mode | |||||||
| Material | Exterior/interior | Stainless steel SUS304,A3 cold rolled steel sheet(milky white)/stainless steel SUS304 | ||||||
| Insulation | PUF+fibrous glass | |||||||
| Regulator | Heater | Heater with nickel-chrome heating wire | ||||||
| Humidifier | External humidification device/steam humidification | |||||||
| Fan | Centrifugal motor with long axis,SIROCCO FAN | |||||||
| Refrigerator | French Tecumseh originally imported compressor | |||||||
| controller | Monitor | Independent R&D PLC programming ability;7.2 inch TFT colorful touch screen,Chinese/English menu;touch screen input | ||||||
| Operating mode | Program mode(120 groups programmable;99 segments in maximum/group;constant value; | |||||||
| Setting range | Temp.;-90.00โ~200.00โ,humidity:1.0%~100%RHยฑ1%RH | |||||||
| Display Resolution | Temp.:0.1โ;time:0.1min;humidity:0.1%RH๏ผ(if the device has humidity function) | |||||||
| Input&output | PT100 input,NO.2 SSR control input;No. 16electric relay output;four-point alert+16DI external obstacle alert | |||||||
| Auxiliary properties | Fault alarm and cause &processing prompt;power-off protection;upper and lower temp. Protection;timing function(automatic start-up&stop);Self-diagnose;RAM with Battery protection ;setting value can be saved | |||||||
| Water supply | Mode | Water pump lifting +portable draw water tank+fixed storage tank(resistivity >500โฆm) | ||||||
| Standard assembly | Observation window,1 cable hole (ฯ50mm),2 sets of sample rack,1 cable wire;1 sample power-supply control terminal,4 caster wheels,3 bracing frames | |||||||
| Safety device | Residual current circuit-breaker;overheated ,over current and pressure protection of compressor;temperature fuse;over temperature protection;overheated protection of fan;dry combustion protector;waterway system protection(only for damp-heat type);high and low temperature sealing protection;dehumidification protection of sealing protection | |||||||
