Burner Flame Test Equipment IEC 60695-11-4 Figure A.1 Description
Burner Flame Test Equipment IEC 60695-11-4 Figure A.1 for 50W Flame Fire Hazard Testing
The Burner Flame Test Equipment IEC 60695-11-4 Figure A.1 for 50W Flame Fire Hazard Testing is a professional fire hazard test apparatus manufactured by KingPo. It produces a standardized 50 W pre-mixed methane flame (~20 mm high) as specified in IEC 60695-11-4 Figure A.1, enabling accurate assessment of fire risk and flame propagation on materials used in electrotechnical products.
Testing Principle
- The brass Bunsen burner (ฮฆ9.5 mm ยฑ0.3 mm) generates a stable pre-mixed methane flame. The burner can be positioned at 0ยฐ, 20ยฐ or 45ยฐ to apply the flame to the test specimen. Calibration is performed using the copper block method to confirm the flame delivers exactly 50 W of heat output, ensuring repeatable and standard-compliant fire hazard testing.
Professional Construction & Technical Precision
Key features include:
- ฮฆ9.5 mm ยฑ0.3 mm brass burner for stable 50 W pre-mixed methane flame
- Adjustable burner angles (0ยฐ, 20ยฐ, 45ยฐ) for horizontal and vertical test configurations
- Copper block calibration support to verify exact flame heat output per IEC 60695-11-4
- Robust and safe base design with precise gas flow control for consistent flame height and stability
These elements ensure accurate, repeatable and fully compliant 50W flame fire hazard testing.
Technical Parameters
| Parameter | Specification | Remark / Notes |
|---|---|---|
| Standard | IEC 60695-11-4 Figure A.1 | 50 W test flame apparatus |
| Burner Diameter | ฮฆ9.5 mm ยฑ0.3 mm | Brass construction |
| Flame Type | Pre-mixed methane, ~20 mm high | 50 W nominal heat output |
| Test Angles | 0ยฐ, 20ยฐ, 45ยฐ | Adjustable for different test methods |
| Calibration Method | Copper block with thermocouple | Verifies standardized flame power |
| Material | Brass | High durability and thermal stability |
The Burner Flame Test Equipment IEC 60695-11-4 Figure A.1 for 50W Flame Fire Hazard Testing is used to assess the fire behaviour of materials and components in electrotechnical products during product development, design validation, production quality control and third-party certification. It helps manufacturers ensure compliance with fire safety requirements and reduce fire-related risks.
Procurement Benefits
The burner offers precise ฮฆ9.5 mm diameter, stable 50 W flame output, adjustable angles and copper block calibration support in a robust, easy-to-operate design. It delivers consistent, repeatable test results with minimal maintenance, making it a practical solution for IEC 60695-11-4 fire hazard testing.
Burner Flame Test Equipment Applications
- Electrotechnical products โ 50 W flame fire hazard testing per IEC 60695-11-4
- Material and component manufacturers โ flame propagation and ignition resistance evaluation
- Certification laboratories โ compliance testing according to IEC 60695-11-4
- R&D departments โ optimization of material fire performance
Compliance & Regulatory Assurance
This equipment is designed and manufactured in accordance with IEC 60695-11-4 Figure A.1 for 50 W test flame apparatus. It provides a standardized method to produce a controlled flame for fire hazard assessment, ensuring materials and products meet the required fire safety levels in electrotechnical applications.
For detailed information on IEC 60695-11-4 testing, please refer to the latest edition of IEC 60695-11-4.
Regular verification of flame height, heat output and burner dimensions is recommended to maintain traceability.
Technical Inquiry for Burner Flame Test Equipment
The Core Value We Deliver to You
- ฮฆ9.5 mm ยฑ0.3 mm precision brass burner for 50 W flame
- Adjustable 0ยฐ, 20ยฐ, 45ยฐ test angles
- Copper block calibration for standardized heat output
- Stable and repeatable flame performance
- Robust construction for long-term laboratory use
Tell us your test material or application โ our engineering team will reply with tailored recommendations within 24 hours.
