IEC 60601-1 Test Equipment List by KingPo
This IEC 60601-1test equipment list helps laboratories, medical device manufacturers and certification teams
identify typical instruments, fixtures and materials used for medical electrical equipment basic safety and
essential performance testing.
KingPo structures this page as a practical equipment selection guide. The checklist maps IEC 60601-1 clauses
to test items, required testing equipment and recommended equipment categories for procurement review and
laboratory planning.
This page is an equipment selection framework and website navigation guide. It is not a replacement for the
official IEC 60601-1 standard or IECEE documentation. Final compliance decisions should be based on official
publications and certification body requirements.
As of now, not all available test equipment and customized configurations are listed on our website. If you cannot find the equipment you need, KingPo can provide a complete IEC 62368-1 testing solution tailored to your specific requirements. Contact our technical team for a professional equipment proposal and quotation.
Standard Information
| Standard | IEC 60601-1:2005+AMD1:2012+AMD2:2020 |
| Document Basis | IECEE OD-5003-F1 2025, Template Equipment List, Ed.1.4 |
| Product Scope | Medical electrical equipment |
| Testing Focus | Basic safety and essential performance |
| KingPo Page Purpose | Clause-based IEC 60601-1 test equipment selection and product mapping |
IEC 60601-1 Testing and Measuring Equipment Checklist
Use this checklist to identify typical instruments, fixtures and materials for each IEC 60601-1 test item.
The final column is reserved for equipment mapping. Replace the placeholder equipment text with actual
KingPo product URLs when the corresponding product page is available.
| Clause | Measurement / Testing | Testing / Measuring Equipment or Material Needed | Recommended KingPo Equipment |
|---|---|---|---|
| 4.11 | Power input | Voltage, current or power, and frequency measurement devices; single-phase and three-phase variac supply where required. | Power input test configuration |
| 5.3 | Ambient temperature, humidity and atmospheric pressure | Instruments for recording ambient temperature, humidity and atmospheric pressure. | Environmental monitoring instruments |
| 5.7 | Humidity preconditioning treatment | Climate chamber capable of controlling temperature and humidity. | Temperature and humidity test chamber |
| 5.9.2 | Accessible parts | Force gauge, standard test finger, straight unjointed test finger and test hook. | IEC 60601-1 standard test finger and accessibility probe set |
| 7.1.2 | Legibility of markings | Illuminance meter. | Marking legibility inspection setup |
| 7.1.3 | Durability of markings | Distilled water, ethanol, isopropyl alcohol and timer or stopwatch. | Marking durability test fixture |
| 8.4.2 | Accessible parts including applied parts | Oscilloscope, leads, voltage/current/capacitance instruments, test pin, metal test rod, force gauge and resistor load. | Accessible parts test probes for medical electrical equipment |
| 8.4.3, 8.4.4 | Limitations of voltage and energy | Oscilloscope recorder or equivalent test setup and RCL meter. | Voltage and energy limitation test setup |
| 8.5.4 | Working voltage measurement | Oscilloscope and high-voltage differential probe. | Working voltage measurement setup |
| 8.5.5.1 | Defibrillation protection | 5 kV test circuit, oscilloscope interface circuit and oscilloscope. | Defibrillation protection test system for IEC 60601-1 |
| 8.5.5.2 | Energy reduction test | Energy reduction test circuit, oscilloscope and oscilloscope leads. | Defibrillation energy reduction test system |
| 8.6.4 | Impedance and current-carrying capability | Current source with suitable current, frequency and voltage capability. | Protective earth impedance test setup |
| 8.7 | Leakage currents and patient auxiliary currents | Measuring device, isolation transformers, variacs, voltage measuring instruments, aluminium foil and related circuits. | Medical leakage current tester |
| 8.8.3 | Dielectric strength | High voltage tester, isolating transformer for HV tests and timer. | Medical electrical equipment dielectric strength tester |
| 8.8.4.1 a) | Ball pressure test | Ball pressure test equipment according to IEC 60695-10-2. | IEC 60695-10-2 ball pressure test apparatus |
| 8.8.4.2 | Resistance to environmental stress | Rubber oxygen ageing apparatus. | Rubber oxygen ageing test setup |
| 8.9 | Creepage distances and air clearances | Oscilloscope, leads, callipers, micrometer, spacing gauges, force gauges and standard test finger. | Creepage and clearance measurement tools |
| 8.9.1.7 | Material group classification | Tracking tester. | Tracking index tester for material group classification |
| 8.9.3.4 | Thermal cycling | Heating cabinet. | Heating cabinet or thermal cycling chamber |
| 8.11.3.5 | Cord anchorage | Force gauge and torque gauge. | Cord anchorage test fixture |
| 8.11.3.6 | Cord guards | Weights, angle gauge and radius gauge. | Cord guard bending test setup |
| 9.2.3.2 | Overtravel end stops | Cycle test setup for moving parts against end stops under specified test conditions. | Overtravel end stop endurance test system |
| 9.4 | Instability hazards | Inclined planes or inclinometer, force gauge, test surface, weights, test threshold, strap and timer. | IEC 60601-1 7 cm strap tester for grip and handling checks |
| 9.5.2 | Cathode ray tubes | Relevant tests of IEC 60065 or IEC 61965. | Project-specific configuration support |
| 9.6.2.1 | Audible acoustic energy | A-weighted sound pressure level measurement equipment according to applicable acoustic standards. | Acoustic measurement configuration support |
| 9.6.3 | Hand-transmitted vibration | Vibration measurement equipment according to ISO 5349-1. | Vibration measurement configuration support |
| 9.7.5 | Pressure vessels | Hydraulic pressure test apparatus and timer. | Hydraulic pressure test apparatus |
| 9.8 | Hazards associated with support systems | Weights or load cell, test surface, timer and human body test mass. | Support system load test equipment |
| 10.1 | X-radiation | Radiation meter. | Radiation measurement configuration support |
| 10.3 | Microwave radiation | Radiation meter. | Microwave radiation measurement support |
| 10.4 | Lasers | Laser safety test equipment according to IEC 60825-1. | Laser safety test configuration support |
| 11.1 | Excessive temperatures | Temperature recorder, thermocouples, resistance unit, test corner and variac. | Temperature rise test system |
| 11.2 | Fire prevention | Spark ignition test apparatus and oxygen gas analyzer. | IEC 60601-1 Figure 34 spark ignition test apparatus |
| 11.3 | Constructional requirements for fire enclosures | FV flammability tests according to IEC 60695-11-10. | Fire enclosure flammability test chamber for IEC 60695-11-10 |
| 11.6.2 | Overflow | Inclined plane or inclinometer, timer and high voltage tester. | Overflow test setup for medical electrical equipment |
| 11.6.3 | Spillage | Flask or graduated cylinder and timer. | Spillage test setup for medical electrical equipment |
| 11.6.5 | Ingress of water or particulate matter | Ingress protection classification tests according to IEC 60529. | IEC 60529 water ingress test equipment for medical devices |
| 11.6.6 | Cleaning and disinfection | Dielectric strength and leakage current test equipment as appropriate. | Dielectric strength tester for post-cleaning safety verification |
| 11.6.7 | Sterilization | Sterilization setup according to client specification. | Sterilization-compatible safety test configuration |
| 11.7 | Biocompatibility | Test instruments complying with ISO 10993 series requirements. | Project-specific configuration support |
| 13 | Hazardous situations and fault conditions | Timer, voltmeter, ammeter, temperature recorder, thermocouples, resistance unit and cheesecloth. | Fault condition temperature and safety test setup |
| 15.3 | Mechanical strength | Force gauge, circular plane surface, steel ball, hardwood board, step, hardwood doorframe and circulating air oven. | Medical electrical equipment mechanical strength test system |
| 15.4.2 | Temperature and overload control devices | PTC device test requirements according to IEC 60730-1 related clauses. | Control device overload test setup |
| 15.4.3.4 | Primary lithium batteries | Tests identified in IEC 60086-4. | Primary lithium battery test equipment |
| 15.4.3.4 | Secondary lithium batteries | Tests identified in IEC 62133. | IEC 62133 battery thermal abuse tester |
| 15.4.6 | Actuating parts of controls | Force gauge, torque gauge and timer. | Control actuating force and torque test fixture |
| 15.4.7 | Cord-connected hand-held and foot-operated control devices | Force gauge, 30 mm diameter test tool and timer. | Hand-held and foot control device test fixture |
| 15.4.7.3 | Entry of liquids | Ingress protection classification tests according to IEC 60529. | IEC 60529 liquid ingress test equipment for medical devices |
| 15.5.1.1 | Transformers | Transformer winding tester, temperature recorder, thermocouples, variac and loads. | Transformer winding temperature test setup |
| 15.5.2 | Dielectric strength | Special dielectric strength test fixture and timer. | Transformer dielectric strength test equipment |
| 16.6 | Leakage currents | Same basic measuring approach as sub-clause 8.7. | Medical leakage current tester |
| A 10.4 | Light emitting diodes | Optical radiation safety evaluation according to IEC 62471. | LED optical radiation safety configuration support |
| G | Protection against ignition hazards of flammable anaesthetic mixtures | Test rods, timer, gasket test setup, force gauge, gas pressure meter, electrical measuring instruments and flammable mixture test apparatus. | Flammable anaesthetic mixture spark ignition test apparatus |
| G.4.3 | Prevention of electrostatic charges | Antistatic material testing according to ISO 2882. | Antistatic material test configuration support |
| L | Insulated winding wires without interleaved insulation | Sample preparation, dielectric test equipment, flexibility and adherence tools, mandrels, heat shock test equipment and metallic shot. | Winding wire breakdown voltage tester for IEC 60851-5 & Mandrel winding tester for IEC 60851-3 |
Engineering Selection Tips by KingPo for IEC 60601-1 Test Equipment
IEC 60601-1 test equipment selection should not be based only on a clause number. Medical electrical equipment
often requires a coordinated test setup covering leakage current, dielectric strength, accessible parts,
mechanical strength, temperature rise, ingress protection and abnormal operation conditions.
KingPo recommends matching the test equipment configuration with the tested device type, expected laboratory
throughput, calibration requirements and fixture compatibility. For example, leakage current testing requires
stable measuring devices and isolation arrangements, while mechanical strength testing requires repeatable force,
impact, load or rough-handling fixtures.
A common procurement mistake is selecting a generic instrument without considering the complete IEC 60601-1
test workflow. KingPo supports clause-based equipment planning so that laboratories can combine electrical safety
testers, mechanical fixtures, IP test equipment and flammability-related test apparatus into a practical medical
electrical safety test setup.
Related KingPo Standard Pages
Link this page to related KingPo standard pages after they are created. These links should point to other KingPo
standard pages, not product pages. Product links should be placed in the Recommended KingPo Equipment column above.
| Related Standard | Application | Link |
|---|---|---|
| IEC 60601-2-52 | Medical bed safety and essential performance testing | |
| IEC 60601-1-8 | Medical electrical equipment alarm signal testing | IEC 60601-1-8 Medical Alarm Signal Test Equipment |
| IEC 60601-2-2 | High frequency surgical equipment and neutral electrode testing | |
| IEC 60601-2-4 | Defibrillator and defibrillation-related testing | |
| IEC 60529 | Ingress protection testing for water and particulate matter | |
| IEC 60695 Series | Fire enclosure, flammability and ignition risk testing |
Related Applications
IEC 60601-1 Test Equipment
Medical Leakage Current Testing
Patient Auxiliary Current Testing
Accessible Parts Testing
Defibrillation Protection Testing
Mechanical Strength Testing
Ingress Protection Testing
Flammability Risk Testing
Medical Device Compliance Test Equipment
FAQ: IEC 60601-1 Test Equipment
What is an IEC 60601-1 test equipment list used for?
An IEC 60601-1 test equipment list helps laboratories and manufacturers identify instruments, fixtures and materials
commonly required for basic safety and essential performance tests of medical electrical equipment.
What equipment is required for IEC 60601-1 leakage current testing?
Leakage current and patient auxiliary current testing typically requires a measuring device, isolation transformers,
variacs, voltage measuring instruments, aluminium foil and related test circuits. KingPo can map leakage current
equipment to IEC 60601-1 clauses 8.7 and 16.6.
How should laboratories select IEC 60601-1 test equipment?
Laboratories should select equipment according to clause coverage, device category, measurement repeatability,
calibration requirements, fixture compatibility and testing workflow. KingPo supports clause-based equipment planning
for medical electrical safety testing.
Can KingPo support customized IEC 60601-1 test fixtures?
Yes. KingPo can support customized fixtures for medical electrical equipment testing, including mechanical strength,
accessibility, support system loading, rough-handling and device-specific test configurations.
What is the difference between electrical safety testers and mechanical safety fixtures?
Electrical safety testers evaluate items such as leakage current, dielectric strength, power input and working voltage.
Mechanical safety fixtures evaluate accessibility, instability, support systems, impact, load, rough handling and
other physical hazards.
Which IEC 60601-1 clauses are commonly related to IP testing?
IEC 60601-1 clauses such as 11.6.5 and 15.4.7.3 are commonly related to ingress protection testing, which references
IEC 60529 methods for water and particulate matter protection.
Can the Recommended KingPo Equipment column be customized?
Yes. The final column is designed for product anchors. You can replace the placeholder equipment names with actual
KingPo product links according to the product pages available on your website.
Is this page a replacement for the official IEC 60601-1 standard?
No. This page is an equipment selection guide. Users should refer to the official IEC standard, IECEE documents and
certification body requirements for final compliance interpretation.
