64L Temperature and Humidity Chamber – IEC 60068 Environmental Test Chamber (-20℃ to 150℃)
64L Temperature and Humidity Chamber – compact environmental test chamber with precise temperature range -20℃ to 150℃ and humidity 20~98%RH, designed for accurate constant temperature and humidity testing of electronics, automotive parts, plastics and other materials.
- Temperature Range: -20℃ to 150℃
- Humidity Range: 20~98% R.H.
- Temperature Fluctuation: ±0.5℃
- Humidity Fluctuation: ±2% R.H.
- Temperature Error: ≤2.0℃
- Heating Rate: 3.0℃/min (no load)
- Cooling Rate: 1.0℃/min (no load)
- Heating/Cooling Overshoot: ≤±2℃
- Internal Volume: 64 L
- Internal Dimension: W400 × H400 × D400 mm
- Control System: 7-inch TFT LED LCD touchscreen with microcomputer controller
- Standards Compliance: IEC 60068-2-1, IEC 60068-2-78, IEC 60068-2-30, IEC 60068-2-38, IEC 61215, EN 14511, ASTM E1171
- MOQ: 1
- Delivery Period: 30 working days
Temperature and Humidity Chamber Description
64L Temperature And Humidity Chamber -20℃ To 150℃
The 64L Temperature and Humidity Chamber is a compact, high-precision environmental test system manufactured by KingPo. It rapidly and accurately simulates constant temperature and humidity conditions from -20℃ to 150℃ and 20~98% R.H., making it ideal for performance verification of electronics, electrical components, automotive parts, plastics, metals and other materials under harsh climatic conditions.
KingPo Factory Advantages
KingPo is an ISO9001 and CE certified manufacturer specializing in temperature and humidity chambers. We have delivered multiple 64L temperature and humidity chambers to leading electronics manufacturers, automotive OEMs and accredited laboratories worldwide. All units include calibration certificates (additional cost), on-site installation guidance, 1-year warranty and 48-hour technical response from our Dongguan facility.
Professional Construction & Technical Precision
Key features include:
- Precise PID control with ±0.5℃ temperature fluctuation and ±2% R.H. humidity fluctuation
- Fast heating rate of 3.0℃/min and cooling rate of 1.0℃/min (no load)
- SUS#304 stainless steel inner chamber with 1.2 mm thickness and full seal welding
- 7-inch TFT LED LCD touchscreen for intuitive programming and real-time data display
- Tecumseh (France) compressor for reliable refrigeration performance
- Low noise level ≤70 dB(A) for quiet laboratory operation
These elements ensure high accuracy, excellent repeatability and full compliance with international environmental testing standards.
Technical Parameters
Core Test Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | -20℃ to 150℃ |
| Humidity Range | 20~98% R.H. |
| Temperature Fluctuation | ±0.5℃ |
| Humidity Fluctuation | ±2% R.H. |
| Temperature Error | ≤2.0℃ |
| Heating Rate | 3.0℃/min (no load) |
| Cooling Rate | 1.0℃/min (no load) |
| Heating/Cooling Overshoot | ≤±2℃ |
Chamber Construction Parameters
| Parameter | Specification |
|---|---|
| Internal Volume | 64 L |
| Internal Dimension (W×H×D) | 400 × 400 × 400 mm |
| External Dimension (W×H×D) | 680 × 1200 × 1350 mm |
| Interior Material | SUS#304 stainless steel (1.2 mm thickness) |
| Exterior Material | Two-sided galvanized static resin sprayed sheet |
| Controller | 7-inch TFT LED LCD touchscreen |
| Compressor | Tecumseh (France) |
| Power Supply | AC380V, 6 kW |
The 64L temperature and humidity chamber supports critical stages:
- Product Development – Verify performance of new electronics and automotive components under climatic stress
- Certification Testing – Generate data for IEC 60068, EN 14511 and ASTM E1171 compliance
- Quality Control – Batch verification of temperature and humidity resistance in production
- Failure Analysis – Identify risks of material degradation or electrical failure under combined temperature-humidity conditions
It improves product reliability, reduces field failures and accelerates certification for temperature-sensitive materials.
Procurement Benefits
Precise PID control, fast heating/cooling rates and robust SUS#304 construction deliver consistent, repeatable results with minimal operator intervention. Low noise and compact 64L design ensure long-term reliability and easy laboratory integration. This temperature and humidity chamber strengthens environmental validation of electronics and automotive parts, supports multiple international standards and minimizes quality risks. Contact us today for your quote – we will respond within 24 hours with detailed technical specifications and pricing.
Temperature and Humidity Chamber Applications
- Electronics and Electrical Components – Temperature and humidity testing per IEC 60068
- Automotive Parts and Plastics – Climatic durability verification
- Communications and Instrumentation – Performance testing under combined temperature-humidity conditions
- Metals, Food and Chemicals – Material stability evaluation
- Certification Laboratories – Compliance testing for IEC 61215, EN 14511 and ASTM E1171
Compliance & Regulatory Assurance
This equipment is strictly designed and manufactured in accordance with IEC 60068-2-1, IEC 60068-2-78, IEC 60068-2-30, IEC 60068-2-38, IEC 61215, EN 14511 and ASTM E1171 for temperature and humidity testing. It provides a controlled environment for accurate performance verification of materials under combined temperature and humidity conditions, thereby ensuring long-term reliability and safety in electronics, automotive and industrial applications.
For detailed technical requirements on environmental testing procedures, refer to the IEC 60068 series standard overview.
Technical Inquiry for 64L Temperature and Humidity Chamber
KingPo specializes in temperature and humidity chambers. If you require precise environmental testing from -20℃ to 150℃ and 20~98% R.H. for electronics, automotive parts or materials, our engineering team can provide customized configurations and technical support.
The Core Value We Deliver to You
- Wide temperature range -20℃ to 150℃ with fast heating/cooling rates
- Precise ±0.5℃ temperature and ±2% R.H. humidity control
- 7-inch touchscreen with microcomputer controller for easy operation
- Compact 64L chamber with SUS#304 stainless steel interior
- Reliable compliance with IEC 60068, EN 14511 and ASTM E1171 standards
Tell us your test volume, sample types or required temperature/humidity profiles — our engineering team will reply with tailored recommendations within 24 hours.
Temperature and Humidity Chamber Detail Display
64L Temperature and Humidity Chamber FAQs
