Salt Spray Test Chamber โ Economy Model Neutral & Acidic Salt Spray Corrosion Tester
Salt Spray Test Chamber โ professional economy model designed for neutral and acidic salt spray corrosion testing of coatings, electroplating, automotive parts, metals and other materials. It provides a controlled, stable environment to accurately evaluate corrosion resistance under standardized conditions.
- Test Conditions: Neutral (NSS) and Acidic (AS) salt spray (CASS optional on request)
- Test Chamber Temperature: 35โ ยฑ1โ (NSS/ACSS) / 50โ ยฑ1โ (CASS)
- Saturated Drum Temperature: 47โ ยฑ1โ (NSS/ACSS) / 63โ ยฑ1โ (CASS)
- Brine Temperature: 35โ ยฑ1โ / 50โ ยฑ1โ
- Heating Method: Thermal radiation heating
- Internal Material: Imported PP hard plastic plate (acid/alkali/high-temperature resistant)
- Nozzle: Plastic precision nozzle with conical spray device
- Control System: LCD touch screen with USB data export (optional)
- Power Supply: AC 220V, 1ฮฆ, 50 Hz (economy model)
- MOQ: 1
- Delivery Period: 30 working days
Salt Spray Test Chamber Description
Neutral Test Conditions Salt Spray Test Chamber with 1ฮฆ Power Supply Economy Model
The Salt Spray Test Chamber (Economy Model) is a professional corrosion testing system manufactured by KingPo. It is specifically designed to perform neutral salt spray (NSS) and acidic salt spray (AS) tests, providing a stable, controlled environment to evaluate the corrosion resistance of coatings, electroplating layers, anodizing, anti-rust oils, metals, automotive parts and other surface-treated products.
This economy model uses imported PP hard plastic plate for the entire chamber, ensuring excellent acid, alkali and high-temperature resistance with zero aging. The precision plastic nozzle and conical spray device guarantee uniform mist distribution and long service life. The LCD touch screen controller offers intuitive operation, Chinese/English switching, programmable spray time and USB data export capability (optional). The system also features automatic water replenishment and flow/pressure adjustment via high-pressure valve and flow meter, ensuring consistent salt spray deposition and uninterrupted long-term testing.
KingPo Factory Advantages
KingPo is an ISO9001 and CE certified manufacturer specializing in salt spray and environmental corrosion testing equipment. We have delivered numerous salt spray test chambers to leading coating manufacturers, automotive suppliers and accredited laboratories worldwide. All units undergo rigorous factory calibration and are delivered with comprehensive documentation, on-site installation guidance, a full one-year warranty and rapid 48-hour technical response from our Dongguan facility.
Professional Construction & Technical Precision
Key features include:
- High-precision thermal radiation heating for stable temperature control (35โ/50โ ยฑ1โ)
- Precision plastic nozzle and conical spray device for uniform mist distribution and long service life
- Imported PP hard plastic chamber body with excellent acid/alkali/high-temperature resistance
- LCD touch screen controller with programmable spray time and USB data export (optional)
- Automatic water replenishment and flow/pressure adjustment for consistent test conditions
- Comprehensive safety protections including leakage, overload and short-circuit protection
These technical elements combine to deliver exceptional accuracy, repeatability and compliance with international salt spray testing standards.
Technical Specifications
| Parameter | Specification | Remark / Notes |
|---|---|---|
| Test Conditions | Neutral (NSS) and Acidic (AS) salt spray | Economy model โ CASS optional on request |
| Test Chamber Temperature | 35โ ยฑ1โ (NSS/ACSS) / 50โ ยฑ1โ (CASS) | Stable thermal radiation heating |
| Saturated Drum Temperature | 47โ ยฑ1โ (NSS/ACSS) / 63โ ยฑ1โ (CASS) | Precise humidity and spray control |
| Brine Temperature | 35โ ยฑ1โ / 50โ ยฑ1โ | Adjustable for different test modes |
| Internal Material | Imported PP hard plastic plate | Acid/alkali/high-temperature resistant, never aging |
| Control System | LCD touch screen | Programmable spray time, USB data export optional |
| Power Supply | AC 220V, 1ฮฆ, 50 Hz | Economy single-phase power requirement |
The salt spray test chamber supports critical stages:
- Product Development โ Evaluate corrosion resistance of new coatings, electroplating and surface treatments
- Certification Testing โ Generate data for IEC60529, ASTM B117 and ISO 9227 compliance
- Quality Control โ Batch verification of corrosion performance in production
- Failure Analysis โ Identify corrosion mechanisms and improve product durability
It improves product reliability, reduces field failures and accelerates certification for corrosion-sensitive materials.
Procurement Benefits
Precise temperature and spray control with automatic water replenishment deliver consistent, repeatable results with minimal operator intervention. The robust PP construction and low-maintenance design ensure long-term reliability and low operating costs. This economy model salt spray test chamber provides excellent value for neutral and acidic corrosion testing, supports international standards and helps minimize quality risks. Contact us today for your quote โ we will respond within 24 hours with detailed technical specifications and pricing.
Salt Spray Test Chamber Applications
- Coatings, Paints and Resins โ Neutral and acidic salt spray corrosion testing
- Electroplating and Anodizing Layers โ Surface treatment durability evaluation
- Automotive and Metal Parts โ Corrosion resistance verification
- Anti-Rust Oils and Protective Coatings โ Performance assessment
- Certification Laboratories โ Compliance testing per IEC60529 and ASTM B117
Compliance & Regulatory Assurance
This equipment is strictly designed and manufactured in accordance with IEC60529, ASTM B117 and ISO 9227 for neutral and acidic salt spray testing. It provides a controlled environment for accurate evaluation of corrosion resistance, thereby ensuring long-term reliability and safety in coatings, metals and industrial applications.
For a comprehensive technical explanation of salt spray testing methods, including detailed requirements and procedures for ASTM B117 and ISO 9227, refer to the Salt spray test technical reference.
Calibration certificates are available at additional cost. Regular verification of temperature, spray flow and concentration is recommended to maintain traceability.
Technical Inquiry for Salt Spray Test Chamber
KingPo specializes in salt spray and environmental corrosion testing equipment. If you require precise neutral and acidic salt spray testing for coatings, electroplating or automotive parts, our engineering team can provide customized configurations and technical support.
The Core Value We Deliver to You
- Precise temperature and spray control with automatic water replenishment
- Imported PP chamber body with excellent acid/alkali resistance
- LCD touch screen controller with programmable cycles and USB data export
- Uniform mist distribution and long service life precision nozzles
- Reliable compliance with IEC60529, ASTM B117 and ISO 9227 standards
Tell us your material types, required test volume or specific standards โ our engineering team will reply with tailored recommendations within 24 hours.
Salt Spray Test Chamber Detail Display
